Project Description

Iridium Gateway for the transmission of measurement data to the cloud
Wireless connection between PreonCubes and PreonLive portal my.virtenio.com
Compact satellite radio gateway (IEEE 802.15.4 for IRIDIUM | SBD)
Integrated GPS/GLONASS module for location determination
Continuous wireless connection from measuring point to cloud
Secure radio communication (min. 128 bit AES encryption)
Modular compatibility with all PreonCubes
Internal antenna IEEE 802.15.4, external antennas for IRIDIUM and GPS/GLONASS
Powered by lithium battery, rechargeable with USB power supply unit
Robust housing (IP 65) with pressure compensation valve
Dimensions 155 x 130 x 75 mm (L x W x H)
Description
The PreonGate IRIDIUM Gateway with GPS functionality establishes the connection between any PreonCube and the Virtenio online portal. It uses a mobile radio connection and transmits the data of the numerous measuring points, such as those of PreonCube Logistics Advanced, to the online portal PreonLive . The PreonCubes also transmit their data wirelessly via IEEE 802.15.4, so all communication from the sensor to the cloud is wireless. IEEE 802.15.4 serves Virtenio’s cubes and gateways as a universal framework format for simple point-to-point communication protocols up to 6LoWPAN (multi-hop network) with duty cycling (optional). For operation, the gateway uses a powerful lithium-ion accumulator, which enables operation for several weeks independent of the mains supply. The battery can also be recharged during operation via a USB-A socket. The closed housing allows the use under demanding environmental conditions. The data can be analyzed and exported via the PreonLive online portal using a web browser. This allows you to monitor your remote measurement cubes from any PC, smartphone or tablet with Internet access and have an overview of their local environmental conditions at all times (24/7).
Connectivity
The PreonGate IRIDIUM Gateway connects the local Virtenio radio network directly to the IP-based Internet. As a result, there are no local requirements for the communication infrastructure worldwide. There is no need for additional hardware, software or power supply. The PreonGate IRIDIUM gateway is prepared for future applications in the area of “Internet of Things and Services” and can be updated to support 6LoWPAN (Multi-Hop functionality) via IEEE 802.15.4 via a software update.




Applications
Areas of application: Logistics, transport, warehousing and building services and offshore
Usage: Accurate monitoring of transports, processes, machines and buildings, etc.
24/7 monitoring, verification, control and alarming
Spot checks or long-term measurements
Technical data
General information | |
---|---|
Dimensions | 155 x 130 x 75 mm (L x W x H) |
Weight | 630 g |
Case | Polycarbonate |
Safety class | IP65 (housing) with pressure compensating valve |
Power supply | Lithium-ion battery with 13400mAh capacity; power supply with USB connection |
Operating modes | Battery; power supply with 5V@1A |
Operating temperature | -20°C to +50°C; 0°C to +40°C (power supply operation) |
Interaction | Non-contact reed switch, LED (three colour) |
Connection | Robust, waterproof socket for power supply unit, SMA sockets for external antennas |
Radio communication (WPAN) | |
Radio frequency | 2.4 GHz, license-free ISM band |
Radio standard | IEEE 802.15.4 |
Range (up to) | outdoor 300m / indoor 30m |
Security | At least 128 Bit AES |
Radio protocol | Point-to-point: proprietary; Mesh network: 6LoWPAN (optional) |
Radio channels | 16 |
Antenna | internal in housing (optional external) |
Communication (IRIDIUM) | |
Frequency bands | 1616 to 1626.5 MHz |
Transmitting power | 1.6W (max.) |
Radio standard | Iridium SBD |
Transmission interval | 6 hours (standard, programmable) |
Antenna | external on housing (optional with cable extension) |
Positioning | |
Radio standard | GPS and GLONASS |
Precision | 2.5 m |
Antenna | internal in housing (external optional) |
Other technologies | Triangulation via IRIDIUM |
Norms and standards | |
Electrical safety | EN 62368-1, EN 62311 |
EMC | EN 301 489-1,-17,-52 |
Radio | EN 300 328, EN 303 413, EN 301 511, FCC Part 15 |
RoHS | EN 50581 |
